Product code: PFF19-2201G
PFF19-2201G Front Arm Front Bush Camber Adjust is made using our Black 95A material and features a machined stainless steel sleeve and spanner, allowing for up to +/- 0.5° of camber adjustment to fine-tune the setup for road or track use.
OEM Part Number: 2201370 / H1BC-3042-AE
OEM Part Number: 2337412 / H1BC-3051-AF
Bushes: per Car 2
Diagram reference: 1
Fitting Instructions:
1. Remove the original bush from the arm.
2. Clean any dirt or burrs from the bore in the arm. Remove any sharp edges
with a rounded file.
Tip: To aid fitment, apply some washing up liquid to the bore of the arm and
body of the bush.
3. With the chamfered lip of the polyurethane bush facing the rear of the car,
press in the bush into the arm
4. Apply the supplied grease to the bore and the mounting faces of each
bush.
5. Fit the stainless-steel sleeve into the bushes with the machined end facing
forwards and then add the machined hex adjuster.
6. For maximum camber, use the supplied spanner to rotate the sleeve so that
the bore is positioned as shown in figure 2.
7. Refit arm and tension all hardware to manufacturers recommended torque
settings
